Hikvision DS-KIS604-P IP Video Intercom Kit

Name: Hikvision DS-KIS604-P IP Video Intercom Kit
Brand: Hikvision
SKU: 10087
Price: 988 SAR
Availability: InStock

SKU: 10087 · Model: DS-KIS604-P

SAR 988

Includes 15% VAT

In Stock

Branch Stock

Riyadh Branch	In Stock
Al Qassim Branch	In Stock

Riyadh Branch In Stock

Al Qassim Branch In Stock

Quantity

24-month official warranty

Estimated delivery: 2-5 business days

Specifications

Model DS-KIS604-P(D)

Product Type IP Video Intercom Kit

Application Villa / House

DOOR STATION

Operating System Embedded Linux

Flash 32 MB

RAM 256 MB

Supplement Light IR

Main Stream Resolution 1920 × 1080p, 1280 × 720p

Sub Stream Resolution 1280 × 720p, 640 × 480

Lens 1

WDR Supported

Field of View Horizontal 124°, Vertical 75°

Video Compression H.264, H.265, MJPEG

Audio Input Built-in omnidirectional microphone

Audio Output Built-in loudspeaker, >80 dB within 30 cm

Audio Quality Noise suppression and echo cancellation

Volume Adjustment Adjustable

Audio Compression G.711u, G.711a, G.726, AAC_LC, AAC_LD, OPUS, G.722.1

Audio Compression Rate 64 Kbps

User Capacity 2,000

Network Protocol TCP/IP, RTSP, IPv6, ONVIF

Wi-Fi 802.11 b/g/n

Wired Network 10/100 Mbps self-adaptive Ethernet

Network Interface 1

RS-485 1

Lock Control 2

Alarm Inputs 4

Exit Buttons 2 Max.

Door Contacts 2

Power Interface 1

TAMPER 1

TF Card 1 (Reserved)

Call Button 1

Power Consumption <10 W

Power Supply Standard PoE / 12 VDC

PoE Standard IEEE 802.3af

Working Temperature -40°C to 53°C

Working Humidity 10% to 95%

Protection Level IP65, IK08

Installation Surface Mounting

Application Environment Outdoor

Dimensions 174 × 91 × 29 mm

Weight 380 g

INDOOR STATION

Operating System Embedded Linux

ROM 32 MB

RAM 128 MB

Processor Embedded high-performance processor

Screen 7-inch colorful TFT touchscreen

Resolution 1024 × 600

Audio Input 1 built-in omnidirectional microphone

Audio Output 1 built-in loudspeaker

Audio Compression G.711u, G.711a, OPUS, AAC-LD, AAC-LC, G.726, G.722.1

Audio Compression Bitrate 64 Kbps

Audio Quality Noise suppression and echo cancellation

Volume Adjustment Adjustable

Notice Capacity 200

Linked Network Camera Capacity 16

Linked Indoor Extension Capacity 16

Linked Doorphone Capacity 17

Network Protocol TCP/IP, RTSP, SIP, IPv6, ONVIF

Wi-Fi 802.11 b/g/n

Bluetooth Reserved

Alarm Inputs 8

Network Interface 1 × RJ-45, 10/100 Mbps self-adaptive

RS-485 1

TF Card Up to 128 GB

Power Supply Output Max. 12 VDC, 0.2 A (PoE powered)

Debugging Port 1

Relay 2 relays, Max. 30 VDC, 0.3 A

Power Supply IEEE 802.3af Standard PoE / 12 VDC

Power Consumption ≤12 W

Working Temperature -10°C to 50°C

Working Humidity 10% to 90% (non-condensing)

Dimensions 200 × 140 × 23.3 mm

Installation Surface Mounting

Application Environment Indoor

Weight 339.1 g (without package)

Key Features

IP video intercom kit for villas and houses
1080p Full HD door station camera
One call button for easy visitor calls
124° horizontal and 75° vertical field of view
IR supplementary lighting for low-light conditions
WDR support for improved image quality in challenging lighting
H.264, H.265 and MJPEG video compression
Two-way audio communication
Noise suppression and echo cancellation
Convenient Hik-Connect APP mobile control
2.4 GHz Wi-Fi support
Supports TCP/IP, RTSP, IPv6 and ONVIF
Door station supports 2 lock controls
4 alarm inputs and 2 exit button inputs
IP65 and IK08 protection for outdoor use
7-inch colorful TFT capacitive touchscreen indoor station
1024 × 600 display resolution
Indoor station supports up to 16 network cameras
Supports up to 16 linked indoor extensions
Supports up to 17 linked doorphones
TF card support up to 128 GB on indoor station
2 relay outputs on indoor station
Standard PoE / 12 VDC power supply

Warranty

24-month official warranty

The Hikvision DS-KIS604-P is a 2MP villa video intercom kit similar in tier to the DS-KIS603-P, with a wide 124° horizontal field of view and built-in WDR and IR supplement light for reliable identification in varied lighting. It ships with a 7-inch touchscreen indoor monitor (DS-KH6320-WTE1) and a 16GB TF card for local recording out of the box. Two-way audio runs at 64 Kbps with a loudspeaker rated above 80dB at 30cm, ensuring clear communication with visitors even in noisier entryways. The system connects over standard PoE or 12VDC, with both WiFi and 10/100 Mbps wired networking supported. Rated to operate from a wide -40°C to 53°C, this kit is built to handle demanding outdoor conditions reliably -- a solid choice for Saudi villas and homes where the door station is exposed to full sun and heat for much of the year.

No questions yet. Be the first to ask about this product.

Ask a Question

Your Name

Your Email

Your Question

FAQ

Q1: What is the DS-KIS604-P(D)?
A: The DS-KIS604-P(D) is an IP video intercom kit designed for villas and houses. It includes a door station and a 7-inch indoor station.

Q2: What is the resolution of the door station camera?
A: The door station supports a main stream resolution of up to 1920 × 1080p (1080p Full HD).

Q3: Does the door station support night vision?
A: Yes. The door station features IR supplementary lighting for low-light conditions.

Q4: What is the field of view of the door station?
A: The door station provides a horizontal field of view of 124° and a vertical field of view of 75°.

Q5: Does the system support two-way audio?
A: Yes. It has a built-in omnidirectional microphone and loudspeaker, with noise suppression and echo cancellation.

Q6: Can I control the intercom system from my phone?
A: Yes. The product supports convenient mobile control through the Hik-Connect APP.

Q7: Does the system support Wi-Fi?
A: Yes. Both the door station and indoor station support 802.11 b/g/n Wi-Fi.

Q8: Does the door station support door lock control?
A: Yes. The door station supports up to 2 lock controls.

Q9: How many alarm inputs are available?
A: The door station has 4 alarm inputs, while the indoor station has 8 alarm inputs.

Q10: Is the door station suitable for outdoor installation?
A: Yes. The door station is designed for outdoor use and has IP65 and IK08 protection ratings.

Q11: What type of display does the indoor station have?
A: The indoor station has a 7-inch colorful TFT capacitive touchscreen with a resolution of 1024 × 600.

Q12: How much TF card storage does the indoor station support?
A: The indoor station supports a TF card with a capacity of up to 128 GB.

Q13: How many network cameras can be linked to the indoor station?
A: The indoor station supports up to 16 linked network cameras.

Q14: How many additional indoor stations can be connected?
A: The system supports up to 16 linked indoor extensions.

Q15: What power options are available?
A: Both stations support standard PoE and 12 VDC power. The door station uses IEEE 802.3af standard PoE.

Q16: What is included in the kit?
A: The kit includes DS-KV8113-WME1(C) ×1, DS-KH6320-WTE1(B) ×1, DS-KABV8113-RS/Surface ×1, Administrator Card ×1, Key Fob ×5, and PSU ×2.
