Hikvision DS-KIS610-P

Name: Hikvision DS-KIS610-P
Brand: Hivision
SKU: HIKVISION-DS-KIS610--2429
Price: 978 SAR
Availability: InStock

SKU: HIKVISION-DS-KIS610--2429 · Model: DS-KIS610-P

SAR 978 SAR 1,093 -11%

Includes 15% VAT

In Stock

Branch Stock

Al Qassim Branch	In Stock
Riyadh Branch	In Stock

Al Qassim Branch In Stock

Riyadh Branch In Stock

Quantity

Manufacturer warranty applies

Estimated delivery: 2-5 business days

Specifications

DOOR STATION

Model DS-KV6114-WBE1

Processor Embedded high performance processor

Operating System Linux

Main Stream Resolution 4MP 2688 × 1520, 2MP 1920 × 1080, 1MP 1280 × 720

Sub Stream Resolution 2MP 1920 × 1080, 1MP 1280 × 720, 0.3MP 640 × 480

Lens 1

Field of View Horizontal 150°, Vertical 75°

Video Compression H.264, H.265, MJPEG

Supplement Light IR light up to 3 m

User Capacity 2,000

Card Capacity 6,000

Network Protocol TCP/IP, SIP, RTSP, IPv6, ONVIF

Wi-Fi 2.4 GHz

Wi-Fi Type Wi-Fi 6

Bluetooth Supported

Wi-Fi Protocol IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ax

Card Reading Frequency 13.56 MHz

Authentication Card, Bluetooth, Indoor Station, Hik-Connect

Card Type M1 Card

Card Reading Distance 2 to 2.5 cm

Mobile App Hik-Connect

Motion Detection Supported

Playback Supported

Call Elevator Supported

Network Interface 1 × RJ-45, 10/100 Mbps

Exit Button 1

Lock Control 2 relays, maximum 30 VDC 2 A

RS-485 1

Door Contact Input 1

Alarm Input 4

Alarm Output 0

Tamper 1

TF Card Up to 128 GB

Power Consumption Less than 10 W

Working Temperature −40°C to 60°C

Working Humidity 10% to 90%, non-condensing

Application Environment Outdoor

Protection Level IP65

Installation Surface mounting

Dimensions 164 × 69 × 24.7 mm

Weight 273 g without package

Power Supply 12 VDC, 1.2 A, IEEE 802.3at, standard PoE

INDOOR STATION

Audio Input 1 built-in omnidirectional microphone

Audio Output 1 built-in loudspeaker

Audio Quality Noise suppression and echo cancellation

Audio Compression G.711u, G.711a, Opus, AAC-LD, AAC-LC, G.726, G.722.1

Audio Compression Bitrate 16 to 64 Kbps

Wired Network 1 × RJ-45, 10/100 Mbps

Wireless Network 2.4 GHz, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

Network Protocol TCP/IP, SIP, RTSP

RS-485 1, half duplex

Alarm Inputs 8 channels

Relay Output 2

TF Card Up to 128 GB

Power Consumption Less than 10 W

Power Supply 12 VDC, 1 A, IEEE 802.3af, Standard PoE

Working Temperature −10°C to 50°C

Working Humidity 10% to 90%, non-condensing

Dimensions 174.99 × 113.49 × 21 mm

Key Features

4MP high resolution door station
150° horizontal and 75° vertical viewing angle
Multiple unlocking methods including M1 card, Bluetooth, indoor station and Hik-Connect
Two lock control
Infrared illumination up to 3 meters
2.4 GHz Wi-Fi and Wi-Fi 6 support
Bluetooth connectivity
Video recording and playback
Hik-Connect mobile app support
Motion detection
Smart sound classification for scream, glass breaking and crying sounds
IP65 outdoor protection
Standard PoE power supply
TF card support up to 128 GB
Two way audio with noise suppression and echo cancellation
Linux operating system

The Hikvision DS-KIS610-P is an IP video intercom kit designed for villas, houses, offices, and residential entrances. It combines a 4MP outdoor door station with an indoor station to provide clear visitor communication and convenient access control. The door station features a 150° horizontal viewing angle, infrared illumination, IP65 protection, Wi-Fi, Bluetooth, and multiple unlocking methods. Users can unlock the door using an M1 card, Bluetooth, the indoor station, or the Hik-Connect mobile app. The system supports two lock controls, video recording and playback, motion detection, and smart sound classification for sounds such as screaming, glass breaking, and crying. Standard PoE is also supported for convenient network connectivity and power delivery. The complete kit includes the DS-KH6350-WTE1 indoor station, DS-KV6114-WBE1 door station, DS-KABV6114-RS, two power supplies, one administrator card, and five key fobs.

No questions yet. Be the first to ask about this product.

Ask a Question

Your Name

Your Email

Your Question

FAQ

Q1. What is the Hikvision DS-KIS610-P?

The Hikvision DS-KIS610-P is an IP video intercom kit designed for residential entrances, villas, houses and similar applications.

Q2. What is the camera resolution?

The outdoor door station supports up to 4MP resolution with a 150° horizontal viewing angle.

Q3. How can the door be unlocked?

The system supports unlocking through an M1 card, Bluetooth, the indoor station and the Hik-Connect mobile app.

Q4. Does the system support two locks?

Yes. The door station supports control of two locks through two relay outputs.

Q5. Does it support Wi-Fi?

Yes. The door station supports 2.4 GHz Wi-Fi and Wi-Fi 6.

Q6. Can I control the intercom using my smartphone?

Yes. The system supports the Hik-Connect mobile application.

Q7. Is the outdoor unit suitable for outdoor installation?

Yes. The door station is designed for outdoor use and has IP65 protection.

Q8. Does the system support video recording?

Yes. The system supports video recording and playback. The door station supports a TF card of up to 128 GB.

Q9. What unlocking methods are supported?

M1 card, Bluetooth, indoor station and Hik-Connect are supported.

Q10. Does the kit support PoE?

Yes. The system supports standard PoE power supply.
